🚀 Getting Started: w/ ZimaBoard

DIY Tutorials for ZimaBoard & Casa Os

First Look at the Home Server

Whether you are an expert or a novice, this Quick Start tutorial will take you through the basic hardware specifications of the ZimaBoard, the basic applications of the pre-built home server, and some basic account permission systems for debugging and development.

With this short tutorial, you will be able to set up a brand-new personal data center in your home in under 15 minutes. Let's get started!

Hardware Preparation

* Tips

  • You don’t need to connect your mouse and keyboard to the ZimaBoard; you can access all the services on the ZimaBoard directly through the network after connecting the network cable.
  • For the first time, it is still recommended that you use the miniDP / miniDP to HDMI with a screen, and remember your ZimaBoard IP address.

Power and Network Cable Connection

  1. Connect the power cable to the ZimaBoard.
  2. Connect the network cable to the ZimaBoard and your router.

Get Started with the System in Three Steps

* Tips

  • You need a computer.
  • Make sure your computer is connected to the same router as the ZimaBoard.

Step 1: Access the System

  1. Open a new tab in your browser.
  2. Enter: http://casaos.local

If you find that http://casaos.local cannot access CasaOS, please use the IP address to access the system.
Tutorial to Find the IP Address

Step 2: Enter the System

  1. You will be prompted to create your account.
  2. Click on CasaOS Create Account.
  3. Follow the on-screen instructions to complete the account setup.

Step 3: Update the System

  • Updating the system will enable a better experience.
  • Navigate to the System or Settings section in the CasaOS dashboard and check for updates.

Default Account for Pre-installed Apps

  • Username: casaos
  • Password: casaos

How to Find the IP Address

  1. Connect your computer to the same network as the ZimaBoard.
  2. Open a terminal or command prompt.
  3. Run the following command:
arp -a
  • Look for the ZimaBoard's MAC address in the output.
  • Alternatively, check your router's connected devices list.

Hosting Apps

The ZimaBoard comes with a variety of pre-installed applications, including:

  • MineCraft Server
  • Jellyfin Server
  • Syncthing
  • Retro Game
  • Oculus VR
  • Enable WOL (Wake-on-LAN)

You can also self-deploy applications using Docker or other methods.

Additional Resources

More Information

For more details on the ZimaBoard hardware and software capabilities, visit the ZimaBoard official documentation.
